REPLACES THE STRAIGHT EDGE AND KNIFE

Features a unique plastic knife design that allows quick and safe blade changes, a lock-down pressure clamp tightly securing materials during the cutting process and a “lock and cut” function for operator cutting control. Cutting capacity of 62” (1.57m).

Use as a tabletop or wall-mounted cutter.


Part Numbers
P/N Description
04-722 F-60 Substrate Cutter
05-235 Knife Blade Jacket Replacements/Box of (10)
04-723 Wall-mount Accessory Kit
17-811 Sight Line Replacement Kit
F-60 Substrate Cutting Capability

Semi-Rigid Materials

  • Foamboard Up to 1/2'' (13 mm)
  • Corrugated Plastics (Up to 6mm)
  • PVC (Up to 3 mm)
  • Cardboard
  • Matboard Sizing

Flexible Substrates

  • Canvas & Vinyl
  • Banner Materials
  • Laminated Art/Photo Mounted on Foamboard
  • Digital Prints, Photo Paper

Cutting Capacity: 62” (1.57M)

Purchase Package

F-60 Purchase Package – includes (3) Plastic Knife Blade Jackets

Table Construction

  • 1.5mm sheet metal table construction preventing warping of cutting table over time
  • Lock down pressure clamp - Improves cutting control and edge quality by securely
    holding material in place while cutting rigid substrates
  •  Equipped with built-in squaring arm to securely hold the material for 90° cutting
  • Full table measuring graphic grid for straight line and angle cutting of 30°, 45°, 60°
    and 75° - includes spare part numbers for easy re-ordering reference
Wall-Mounted Set-up
  • Easy to install on any wall
  • Requires wall foot print of:
    74” (1.88M) x 44” (1.12M)
  • Cutting head carriage can be field adjusted when used in the wall-mount set-up configuration – head remains stationary  above material prior to cutting process
  • No loose hardware – contains all threaded inserts
  • Hanging weight: 45 lbs. (20.5 kg)

Replacement Parts & Accessories


P/N:

Replacement Cartridges (10/box)

Wall Mount Kit

05-235

04-723

Technical Documents
F60_ownersmanual.png F60_Sellsht.png
F-60 Manual F-60 Semi-Rigid/Flexible Cutter

Performance Features & Dimensions

  • Features a unique plastic knife blade cartridge allowing quick and safe blade changes
  • Cutting head equipped with “Lock & Cut” feature – cutting head lowers and locks during cutting process
  • Lock down pressure clamp – securely holds material in place while cutting ridge substrates
  • Table-top or wall-mounted cutting

Plastic Knife Blade Cartridge – Window Shade

  • Utilizes a .015" thick blade providing exceptional cutting and edge quality with all paper based products as well as PVC materials up to 3mm thickness
  •  Blade is permanently molded into a plastic jacket for safe handling
  •  Allows for quick blade change
  • Contains four measuring settings indicating depth of cut

Q. Can I use standard, off-the-shelf cutting blades?

A. For achieving the best quality edge and square cut, we recommend only the use of Fletcher designed and branded cutting blades. This will ensure:

  • Better life and cutting performance
  • Blade-to-blade performance consistency
  • Minimized “Blade Deflection” when cutting rigid substrates




Cutting Head Features


  • Cutting head unit equipped with “Lock & Cut” feature – cutting head lowers and locks during cutting process
